Suzaku 440W Beam Pattern Light

Product Status: Regular Product
Place of Origin: China (Guangzhou)
Product model: FLY-440BSW
Product power: AC220V/110V, 50/60Hz
Certified: CE ROHS ISO9001
Product packaging: carton (air box optional)
Brand Name: Jianuo Lighting "LIGHT FLY"
Production method: OEM; ODM; OBM

Parameters

Effect

Video

1.Light and power system:
Input voltage	AC90～240V/50～60Hz	Light source life	2000 Hour
Total power	600W	Light source color temperature	6500K Linear adjustment
Product light source	OSRAM SIRIUS HRI 440W	Focus function	Linear motorized focus
Lighting motherboard	440W Universal multifunctional electronic ballast	Dimming function	Dual dimming panel dimming, super smooth and flicker-free
Power source	440W Three-level power free adjustment	Strobe function	Independent strobe, adjustable from 0.5 to 20 times/second

2.Color/Pattern/Effect：
color wheel effect	13+1 Color wheel, bidirectional rotating rainbow effect	Prism effect	16 prism + trapezoidal prism / 16 prism + 24 prism optional
Fixed pattern	14+1 Fixed gobo, bidirectional shaking, water effect	beam angle	BEAM mode 0～1.5°; SPOT mode 10～50°
Rotation pattern	9+1 Active pattern, bidirectional dithering water effect	diffuser lens	8°～60° Independent soft light effect

3.Control System:
control method	Standard DMX512 channel mode	Projection range	X direction 540 degrees, Y direction 270 degrees can automatically correct the positioning
control mode	Standard 16ch/Extended 20ch	Scan speed	X direction 2.9 seconds/540 degrees, Y direction 1.5 seconds/270 degrees

4.Appearance parameters:
Lamp material	High-strength PA66, high temperature resistance, anti-aging	carton size	450X430X730(mm)（1 tower）
Protection class	IP20	Net weight/gross weight	19.4KG / 23KG
Lamp body size	330X358X529(mm)	air box	900×630×715(mm) (2 Taiwanese)
Product Weight	19.4KG	Net weight/gross weight	38.8KG / 80.3KG

5.other functions:

Other functions

The menu has a recording function, which shows the use time of the lamps and lanterns, and the fan automatically adjusts the speed. When the light is turned off, the power can be reduced by 60W.

Custom Accessories

Customization is not supported for less than 50 moving head lights, and customization is not supported for less than 100 LED lights. Custom parts lead time increases by 15-30 days.

(Customized accessories such as: light source, gobo, color chip, LOGO, packaging, LED lens angle, etc.).
